- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Line
- AirborneM2M
- Marketing Information
- Model BB-APXN-Q5420 industrial wireless access point is built for networking equipment in an array of machine-to-machine (M2M) applications. The AirborneM2MTM access point features industrial strength packaging and a wide temperature rating (-40 to +85 °C) to withstand challenging M2M environments.
Combination Access Point and Client Capability
The AirborneM2M access point enables M2M equipment to create a self sufficient Wi-Fi network and provides easy access to equipment data or resources from Wi-Fi enabled devices. The product also has the capability to be switched from an access point to a client; supporting dual RS-232/422/485 serial ports or a single 10/100 Mbps Ethernet port. The Ethernet port can be placed into either router mode or bridge mode.
Dual-Band Wi-Fi
Model BB-APXN-Q5420 establishes wireless connections over 2.4 GHz or 5 GHz bands. Whenever the 2.4 GHz airspace is overcrowded with competing wireless transmissions, the access point can be switched to 5 GHz the band to keep data flowing.
Enterprise Class Security
Security protocols are important to mission critical wireless M2M applications. Model BB-APXN-Q5420 access point's multi-layer security addresses the requirements of Enterprise-class networks and corporate IT departments.
Advanced security features include: wireless security (802.11i/WAP2 enterprise), authentication security using WPA2 (AES-CCMP) and device security (multilayered encryption). The access point includes a fully functional DHCP server to provide unique addresses for each authenticated client. Up to 9 clients can be supported on the local Wi-Fi network.
Power
The access point is powered by an external 5-36 VDC power source (not included, sold separately).
- Product Type
- Wireless Access Point
- Technical Information
- Wireless LAN Standard
- IEEE 802.11a/b/g/n
- Network Band
- Dual Band
- Frequency Band
- 2.40 GHz
- 5 GHz
- Data Encryption
- Yes
- Encryption Standard
- WPA2-ENT
- AES-CCMP
- 64-bit WEP
- 128-bit WEP
- WPA-PSK
- TKIP
- WPA2-PSK
- AES
- WPA-ENT
- Interfaces/Ports
- Ethernet Technology
- Fast Ethernet
- Number of Network (RJ-45) Ports
- 1
- Physical Characteristics
- Form Factor
- Panel-mountable
- DIN Rail
- Antenna Form Factor
- External
- Height
- 1.1"
- Width
- 4.7"
- Depth
- 4.7"
