- Secure access to IT equipment with RS-232 and USB console ports
- Access devices via Telnet/SSH or a Web browser-based console client without any proprietary software.
- Leverage the command line interface of most IT equipment for reconfiguring, rebooting and reloading firmware from a single point of contact.
- Connect in-band with dual Gigabit Ethernet or dual SFPs and through out-of-band connections including dial-up and cellular connectivity options.
- Modular design to deploy what you need at each location, up to 48 ports: RJ-45 serial, Ethernet, or serial USB.
- General Information
- Manufacturer
- Lantronix, Inc
- Manufacturer Website Address
- http://www.lantronix.com
- Brand Name
- Lantronix
- Product Series
- SLC
- Product Type
- Device Server
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Device Type
- Console Server
- Media & Performance
- Media Type Supported
- Twisted Pair
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Standard
- 10/100/1000Base-T
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- Serial Port
- Yes
- Management Port
- Yes
- Number of Network (RJ-45) Ports
- 2
- Number of Serial Ports
- 48
- Power Description
- Input Voltage
- 20 V DC
- 72 V DC
- Physical Characteristics
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 17.3"
- Depth
- 12"
- Weight (Approximate)
- 11.10 lb
- Miscellaneous
- Certifications & Standards
- FCC Part 15
- CE (EN55022, EN55024, EN60950)
- CSA
- VCCI
- UL/CUL
- C-Tick
- CB Scheme
- NIST-certified implementation of AES (Advanced Encryption Standards) as specified by FIPS-197
- IPv6 Ready
- FIPS 140-2
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Country of Origin
- United States
- TAA Compliant
- Yes
