- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- TP-Link
- Product Line
- VIGI
- Product Type
- Video Surveillance Station
Dual Ethernet Ports Design
Multi-Address Mode
Allows for the implementation
of two different gateways
Network Fault-Tolerance
Creates a safeguard or
redundancy for your data
Port Aggregation
Realizes bandwidth stack
and mutual backup
Auto Initialize for Quick Configuration
Just click "Auto Initialize" to set up basic IPC and hard disk parameters, greatly reducing your configuration time.
- Technical Information
- Total Number of Channels
- 16
- Connectivity Technology
- Wired
- Recording Formats
- 4K
- HD Recording
- Yes
- System Components
- Network Video Recorder
- Features
- Motion Detection
- Video
- Video Formats
- H.265+
- H.265
- H.264+
- H.264
- Maximum Resolution
- 8MP
- Maximum Frame Rate
- 30 fps
- Network & Communication
- Ethernet
- Yes
- Remote Management
- Yes
- Interfaces/Ports
- USB
- Yes
- USB Standard
- USB 2.0/3.0
- Number of USB Ports
- 3
- Total Number of Audio In Ports
- 1
- Total Number of Audio Out Ports
- 1
- Number of VGA Out
- 1
- HDMI
- Yes
- Software
- Operating System Supported
- Android
- Apple iOS
- Power Description
- Power Consumption
- 45 W
- Power Source
- AC Supply
- Physical Characteristics
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 13"
- NVR Weight
- 8.82 lb
- Environmental Conditions
- Minimum Operating Temperature
- 14°F (-10°C)
- Maximum Operating Temperature
- 131°F (55°C)
