The E-100BTX-FX-06 is a stand-alone media converter that provides an interface between 100Base-TX ports and 100Base-FX ports, allowing users to integrate fiber optic cabling into 100Base-TX copper environments. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
- General Information
- Manufacturer
- Transition Networks, Inc
- Manufacturer Website Address
- http://www.transition.com
- Brand Name
- Transition Networks
- Product Series
- E-100BTX-FX-06
- Product Type
- Transceiver/Media Converter
- Warranty
- Limited Warranty
- Lifetime
- Interfaces/Ports
- Total Number of Ports
- 2
- Network (RJ-45)
- Yes
- Number of LC Ports
- 1
- Number of Network (RJ-45) Ports
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Fiber Mode Supported
- Multi-mode
- Fiber Optic Cable Wavelength
- 1300 nm
- Maximum Distance Supported
- 2 km
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 100Base-TX
- 100Base-FX
- Power Description
- Power Source
- Power Supply
- Power Consumption
- 1.75 W
- Physical Characteristics
- Form Factor
- Standalone
- Rack-mountable
- Wall Mountable
- DIN Rail Mountable
- Height
- 1"
- Width
- 3"
- Depth
- 4.7"
- Weight (Approximate)
- 2 lb
- Miscellaneous
- Package Contents
- Stand-alone Fast Ethernet Media Converter 100Base-TX to 100Base-FX
- Power Supply (North America)
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
